Hologram Heat Transfer Vinyl Multi Colors

Hologram-Heat-Transfer-Vinyl-HTM-EF-Main

Hologram Heat Transfer Vinyl

0 out of 5

Hologram heat transfer vinyl material has a shiny prism-like finish that features a rainbow effect. The image shifts as the wearer move, creating a distinctive visual effect.

High gloss, shiny prism-like finish
Not recommended for multi-layer applications

SKU: HTM-EF Category: Heat Transfer Vinyls

Download high res image
Download low res image
Download all images As a zip
Download printing instruction As a pdf

To access this section, first Register and then log in

Print Proof
Client Email Address* Separate multiple e-mail addresses with a comma.
Add Message (Maximum 30000 characters)
Your Name

Customize Quotation Sheet

To access this section, first register and then log in

Subject:
Text:

To access this section, first Register and then log in

HTM-EF-COLOR	Clear

Description
Application Instructions
Packaging Details

Description

CAD-CUT? Hologram Heat Transfer Vinyl

Hologram heat transfer vinyl provides a glittering, rainbow-effect finish resembling a prism. As the user moves, the image changes, producing a unique visual impact.

The finish has a prism-like high shine.
Applications with many layers are not advised.

Material Requirements

Material: polyester
Clear Pressure-Sensitive Carrier
100-115 microns thick (.1-.115 mm)
Rebound & Stretch: 2
50 washability
Safety: CPSIA Certified
Compatible with Laser Cutter

1-Color Application Instructions

Time: 10 – 15 seconds
Temperature: 320?F/160?C
Pressure: Firm
Peel: Cold

Hotronix? 360 IQ? Hat Press

Time: 45 seconds
Upper: 280?F
Lower: 320?F
Pressure: Medium
Peel: Warm/Cold
Cover Sheet: 1/8″ Foam Pad

Material/Fabric Compatibility

100% Cotton
100% Polyester
100% Preshrunk Cotton
Cotton/Poly Blends

Care Instructions

Machine wash inside-out using mild detergent.
Do not use bleach. Dry at a normal dryer setting on household machines. Do not dry clean.

Storage

Store in a cool and dry area around 65 to 70 degrees Fahrenheit with 50% relative humidity. Keep away from direct heat, sunlight, and humidity. Recommended shelf life is one year.

Cutter Guidelines

Cutter?????????????????? Blade ?????? Force ?????????????????????????? Offset?????????? Speed

GCC?? ??????????????????? 45?/60????? 90-150g/90-130g????? .25/.50?????????? 20 – 25 cm/s
Graphtec ???????????? 45????????????? 15-17????????????????????????????? 0?????????????????? 30cm/s
Roland GS-24? ?? 45????????????? 140-160g????????????????????? .25???????????????? 30cm/s
